Custom Garage Options
If you are interested in a custom garage door then let us know when you place your order or call us 888-822-7767. We will add a custom frame out that will allow you to install a custom garage door from a garage door company of your choice. A frame out includes custom framing required to support the frame-out option and trim color of your choice so when your custom garage door is installed, it will have a finished look. Custom garage doors often include insulation within the door, motorized openings, and keyless entry.
Our Economy Garage Door Option
Our roll-up door is the right choice for light-duty applications requiring frequent usage such as barns, warehouses, freight terminals, car washes, machine shops, auto body shops and much more. The 16-gauge, 12” drums allow for easy retraction. These doors are low-maintenance, which is what every owner wants in a quality door. Our commercial-grade steel curtain roll-up doors are designed to meet and/or exceed operational requirements for commercial doors with little or no maintenance.
Roll-Up Garage Doors
Technical Data
Curtain
- 26-gauge galvanized
- Grade E hard steel Deep-ribbed corrugation
- Maximum opening size of 12’ x 18’
- Flexible wear strips
- NOTE: The our standard roll-up door is not rated for wind loads. Please ask for a certified door with wind ratings that you require
Bottom Bar
- 6063-T6 aluminum extrusion
- 2” x 1 ½” galvanized angles
- Bulb astragal
- Stainless steel nuts and bolts
Axle-Drum Assembly
- 1 5/16” O.D. steel axle, 14-gauge
- 11-gauge axle on doors over 10’ wide
- Utilizes 12”, 16-gauge drums
- Shielded steel ball bearings in drums
- Full top sheet
A.C.E. Guide System
- 16-gauge galvanized steel
- Adjustable bolt on head stop
- Polyethylene wear strip
- Pre-punched for lock and attachment fasteners
Hardware
- Saddle clamps with set fasteners
- 10-gauge slide locks; 2 per door
- 16-gauge step plate; 2 per door
- ¼” steel angle T-bracket
Opening Height Headroom
- Doors up to 10’ have 20” of headroom
- Doors 10’ to 14’ have 22” of headroom
- Doors over 14’ have 24” of headroom
